The Manfrotto 500X is a video head designed for mirrorless camera users who want precision, smooth movement and complete control. As part of the Bridging Technology series, the 500X combines innovative solutions with reliability and ease of use. It will work well for both video recording and creating content for social media.
Smooth motion and counterbalance lock
Every movement of the camera matters. The Fluid Drag System (FDS) provides smooth and precise movements in pan (left-right) and tilt (up-down) for professional frame guidance. The built-in counterweight system, optimised for a weight of 2.4 kg (with a centre of gravity of 55 mm), facilitates control when filming. It can be deactivated if required, e.g. when shooting, making the head even more versatile.
Fast and reliable mounting
The 500X head is equipped with the popular 501PL sliding plate and a side locking mechanism that allows the camera to be mounted from the top in no time. Not having to slide the plate in from the back speeds up set-up considerably - just one click and you're ready to go.
Universal and ready for any challenge
The 500X head features a flat base with a 3/8'' female thread, ensuring full compatibility with most tripods and accessories - such as sliders and camera carts. In addition, it is fully compatible with Manfrotto's new XCHANGE quick release system, which allows the head to be attached instantly, for example to a Manfrotto ONE tripod. If you do not use this system, the head still works with the classic mounting system - without any limitations.
Ideal for social media creators
The vertical format plays a key role today. Thanks to its innovative design, the 500X allows the head to be tilted quickly and steadily by 90°, allowing you to conveniently create content in a vertical layout. This is perfect for vloggers, TikTok creators, Reels and anyone who creates with mobile devices in mind.
Perfect framing every time
The built-in spirit level allows you to quickly and accurately adjust the horizon - saving time during recording and in post-production. Whatever the shot, with 500X you are guaranteed consistency and a professional result.
Why choose 500X?
- Versatility of operation: Easily switch between panoramic and portrait modes.
- Bridging Technology: An innovative combination of performance and modern design.
- Smoothness of movement: Precise pan and tilt movements thanks to the Fluid Drag system.
- Quick to mount: Secure side locking system - attaches camera in seconds.
- Universal use: Compatible with the XCHANGE system and classic mounts.
- Framing precision: Built-in spirit level for perfect alignment.
Manfrotto 500X technical specifications:
- Weight: 1.22 kg
- Lifting capacity UNI/PdR 105:2021: 5 kg
- Counterweight system: Variable, in steps
- Counterweight: 0, 2.4 kg
- Base diameter: 60 mm
- Material: Aluminium, Technopolymer
- Level (quantity): 1
- Centre of gravity: 55 mm
- Top attachment: 1/4″ male thread, 3/8″ male thread
- Colour: Black
- Easy Link: No
- Front-to-back tilt: -70° / +90°
- Base: Flat base
- Head Type: Video / Fluid Head
- Side tilt: 0° / +90°
- Maximum operating temperature: 60 °C
- Minimum operating temperature: -30 °C
- Handle included: yes
- Adjustable resistance in panorama: fluid cartridge with constant resistance
- Rotation in panorama: 360 °
- Insert type: 501PL
- Quick release plate: Yes
- Panning resistance adjustment: fluid cartridge with fixed resistance
- Height: 11.8 cm
- Accessory compatibility: MAONEQR, 560BALLSHX
